X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO)
450 – 470 MHz, 6.5dBi; 790 – 2170 MHz, 8dBi
The XPOL-16 covers multiple LTE frequency bands, which includes the 450 – 470 MHz, 790 – 860 MHz and 1710 – 2170 MHz. The antenna is an innovative solution to boost the reception of 4G, 3G and 2G network signals. The XPOL-16 is a dual-polarised full LTE band antenna and is wall- or pole-mountable. The antenna is equipped to provide client-side MIMO and diversity support for the networks of today and tomorrow by incorporating two separately fed ultra-wideband elements in a single housing. This is a cost-effective solution for enhancing signal reception and throughput. The XPOL-16 antenna increases signal reliability, ensures higher data throughput for users and provides a stable, high quality connection. This improves subscriber’s user experience and secures client retention. It is ideal for any application using the GSM network (LTE/ HSPA/3G/EDGE/GPRS).
| Weight | 2.54 kg |
|---|---|
| Industry (Application) | Urban & Rural Cellular, IoT, M2M & Smart Meters |
| Technology | CDMA450/LTE-M 450, Cellular (LTE/2G/3G/4G), LoRa, NB-IoT |
| Frequency Band | 1700-1900MHz, 1900-2200MHz, 791-894MHz, 450-470MHz |
| Frequency Range | 450 – 2170 MHz |
| Gain | 8dBi |
| Directionality | Uni-Directional |
| Mounting Type | Pole Mount, Wall Mount |
| Connectors | SMA |
| MIMO | 2×2 |
| Polarisation | X-Polarised |
| Environmental | IP65 |
| Enclosure Name | Leopard |
| Enclosure Size | Medium |
| LTE Ports | 2 |
Key Features
- Futureproof wideband LTE antenna
- Includes the new 450 – 470 MHz frequency band
- Backwards compatible with 3G and 2G technologies
- Two antennas in one enclosure for optimal LTE performance
- Improves mobile network subscriber’s user experience
- Increased connectivity stability
- Weather- and vandal resistant enclosure (IP 65)
